| Model | TD-PH 800 | TD-PH 1200 |
| AC Input (generator / grid) | ||
| Input Voltage Range | 210-230V | |
| Frequency | 50Hz | |
| Mains Charging Efficiency | >95% | |
| DC Input | ||
| Adap tor | 14.6V/8A | |
| Solar energy | 15.4V-22V /5A | |
| AC Output | ||
| Output Voltage | 210-230V | |
| Output Voltage Waveform | Pure Sine Wave | |
| Rated Output Voltage | 230(200/208/220/240Vac) | |
| Rated Output Power | 800W | 1200W |
| Output Frequency Range(Hz) | 50Hz | |
| Maximum Efficiency | >92% | |
| DC Output | ||
| DC Output | 12V5A | |
| Cigarette Lighter Output | 12V/10A (120W Max) | |
| USB Output | ||
| USB-A Output | 5V3A | |
| Type Output | 5V3A | |
| General | ||
| Housing | Metal housing | |
| Screen | AC & DC Voltage Display | |
| LED Light | Lighting+SOS (Rear Light)+Flash | |
| Humidity Range | 5% to 95% (Conformal Coating Protection) | |
| Charging Mode | AC / Car / PV Charger | |
| Working Temperature Range | -15C-55C | |
| Storage Temperature Range | -25C-60C | |
| Product Size | 330*250*210mm | |
| Packing Size | 395*315*305mm | |
| Gross Weight | 10.2kgs | 12.5kgs |
