| Model | TD-AF01-3 | TD-AF01-4 | TD-AF01-5 | TD-AF01-6 |
| Product material | Aluminium alloy | |||
| Lens material | Acrylic optical lens | Acrylic optical lens | Acrylic optical lens | Acrylic optical lens |
| Product size(mm) | 900*389*95 | 1090*389*95 | 1285*389*95 | 1485*389*95 |
| Warranty period | Two years | |||
| Battery capacity(mAh) | 50AH LiFePO4 | 60AH LiFePO4 | 80AH LiFePO4 | 100AH LiFePO4 |
| Solar panel(mono) | 6V/50W 340*890mm |
6V/70W 340*980mm |
6V/90W 340*1175mm |
6/110W 340*1375mm |
| Working Time | More than 12hours | |||
| Number of LED | 60pcs 5050High brightness LED beads | 80pcs 5050High brightness LED beads | 100pcs 5050High brightness LED beads | 120pcs 5050High brightness LED beads |
| Charge time | 4hours | |||
| Discharge current | 3.45V/6A | 3.45V/7A | 3.45V/8A | 3.45V/10A |
| Luminous flux | 4000LM | 6000LM | 8000LM | 10000LM |
| Working mode | Radar induction+Always on light (Side blue light strip) | |||
| Waterproof level | IP66 | |||
| Suitable pole diameter | 60mm or 76mm | |||
